三重处理器监事 TRIPLE PROCESSOR SUPERVISORS
Control the core processor in case of failure with the microprocessor supervisory circuit, developed by Texas Instruments. This device has a maximum power dissipation of 2140 mW. Its maximum power dissipation is 2140 mW. This product will be shipped in tape and reel packaging for quick mounting and safe delivery. It has a typical reset threshold voltage of 4.55|2.93|Adj V, with a minimum of Adj V and a maximum of Adj V. This device has a minimum operating supply voltage of 2 V and a maximum of 6 V. This part has a minimum operating temperature of -40 °C and a maximum of 85 °C.
电源电压DC 2.00V min
供电电流 0.04 mA
耗散功率 2.14 W
静态电流 15.0 µA
阈值电压 2.93V, 4.55V, Adjustable
复位电压Min Adjustable
复位电压Max Adjustable
工作温度Max 85 ℃
工作温度Min -40 ℃
耗散功率Max 2140 mW
电源电压Max 6 V
电源电压Min 2 V
安装方式 Surface Mount
引脚数 8
封装 PowerPad-MSOP-8
宽度 3 mm
封装 PowerPad-MSOP-8
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/06/15
ECCN代码 EAR99
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
TPS3307-33DGNR TI 德州仪器 | 当前型号 | 当前型号 |
TPS3307-33DGN 德州仪器 | 类似代替 | TPS3307-33DGNR和TPS3307-33DGN的区别 |
TPS3307-33DGNRG4 德州仪器 | 类似代替 | TPS3307-33DGNR和TPS3307-33DGNRG4的区别 |
TPS3307-33DGNG4 德州仪器 | 类似代替 | TPS3307-33DGNR和TPS3307-33DGNG4的区别 |
