TSW-108-14-F-S

SAMTEC TSW-108-14F-S Board-To-Board Connector, 2.54mm, 8Contacts, Header, TSW Series, Through Hole, 1Rows

针座 通孔 8 位置 0.100"（2.54mm）

欧时:
HEADER TH 8POS 2.54MM 1 ROW

得捷:
CONN HEADER VERT 8POS 2.54MM

艾睿:
Mount this unshrouded TSW-108-14-F-S header connector from Samtec on a jumper post on your PCB to support physical configuration options. This HDR connector&s;s 8 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a header type gender. It has a straight body orientation. It has a maximum voltage rating of 550 VAC. Its pitch is 2.54 mm. This is a 1-row connector. This device has a maximum current rating of 6.3 A/contact. This product is 20.32 mm long, 10.67 mm tall and 2.54 mm deep. It uses the solder termination method. This connector has an operating temperature of -55 to 125 °C. TSW-108-14-F-S is housed in black polyester.

安富利:
Conn Unshrouded Header HDR 8 POS 2.54mm Solder ST Thru-Hole

Newark:
# SAMTEC  TSW-108-14-F-S  Board-To-Board Connector, 2.54 mm, 8 Contacts, Header, TSW Series, Through Hole, 1 Rows
