TRACOPOWER TML 05212 交流/直流电路板安装电源, 模块式, 固定, 12V, 200mA, -12V, 200mA
The TML series single/dual/triple-output 5 to 30W AC/DC Power Supply features ultra compact and fully encapsulated plastic case. They feature versions with screw terminals for easy installation or with solder pins for direct PCB mounting. International safety approvals qualify this product for worldwide markets. The TML series AC/DC modules offer an interesting solution for many space critical applications in commercial and industrial electronic equipment.
- .
- Universal input voltage
- .
- Low ripple and noise
- .
- Short-circuit protection
- .
- Overload protection
电源电压DC 264 V
额定功率 5 W
输出接口数 2
输出电压 ±12 V
输出电流 200 mA
输出功率 5 W
隔离电压 3000 VAC
输入电压AC Max 264 v
输入电压AC Min 85 v
输出功率Max 5 W
工作温度Max 71 ℃
工作温度Min -25 ℃
电源电压 264 V
电源电压Max 264 V
电源电压Min 85 V
输入电压 85V ~ 264V
安装方式 PCB
长度 55 mm
宽度 45 mm
高度 20.5 mm
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/12/17
