TSM-106-01-S-DH

HEADER, 2.54MM, SMT, R/A, 12POS; Series: TSM; Pitch Spacing: 2.54mm; No. of Rows: 2

针座 表面贴装，直角 12 位置 0.100"（2.54mm）

得捷:
CONN HEADER SMD R/A 12POS 2.54MM

艾睿:
This unshrouded TSM-106-01-S-DH header connector from Samtec reduces the possibility of accidentally shorting pins when a board is being used. This HDR connector&s;s 12 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a right angle body orientation. This is a 2-row connector. Its pitch is 2.54 mm. It has a maximum voltage rating of 475 VAC. It has a header type gender. This device has a maximum current rating of 5.4 A/contact. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This product is 15.24 mm long, 6.1 mm tall and 16.25 mm deep. It uses the solder termination method. This connector has an operating temperature of -55 to 125 °C. TSM-106-01-S-DH is housed in black liquid crystal polymer.

Newark:
# SAMTEC  TSM-106-01-S-DH  Board-To-Board Connector, 2.54 mm, 12 Contacts, Header, TSM Series, Surface Mount, 2 Rows
