UC1708JE883B

双非反相电源驱动器 DUAL NON-INVERTING POWER DRIVER

DESCRIPON

The UC1708 family of power drivers is made with a high-speed, high-voltage, Schottky process to interface control functions and high-power switching devices – particularly power MOSFETs. Operating over a 5 to 35 volt supply range, these devices contain two independent channels. The A and B inputs are compatible with TTL and CMOS logic families, but can withstand input voltages as high as VIN. Each output can source or sink up to 3A as long as power dissipation limits are not exceeded.

FEATURES

• 3.0A Peak Current Totem Pole Output

• 5 to 35V Operation

• 25ns Rise and Fall Times

• 25ns Propagation Delays

• Thermal Shutdown and Under Voltage Protection

• High-Speed, Power MOSFET Compatible

• Efficient High Frequency Operation

• Low Cross-Conduction Current Spike

• Enable and Shutdown Functions

• Wide Input Voltage Range

• ESD Protection to 2kV
