.050 PITCH LFH 160 CKT直角I / O女售楼总成 .050 PITCH LFH 160 CKT RIGHT ANGLE I/O FEMALE SALES ASSEMBLY
160 位 D 型，板至板，阵列 插座，母型插口
得捷:
CONN D-TYPE RCPT 160POS R/A SLDR
艾睿:
Using the 0051241040 DVI connector from Molex is fast and easy for communicating between serial connections in your circuit. Its pitch is 1.27 mm. This female connector&s;s 160 contacts that are made out of beryllium copper and plated with gold over nickel. This 4-row connector has a single port. It has a maximum voltage rating of 40 V. It has a right angle body orientation. 0051241040 is housed in liquid crystal polymer. This device has a maximum current rating of 1 A/contact. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This DVI connector has an operating temperature of -20 to 80 °C. Its 160 terminals use the solder termination method. This product is 69.85 mm long, 9.83 mm tall and 16.77 mm deep.
安富利:
Conn D-Subminiature F 160 POS 1.27mm Solder RA Thru-Hole 160 Terminal 1 Port Tube
Chip1Stop:
Conn D-Subminiature F 160 POS 1.27mm Solder RA Thru-Hole 160 Terminal 1 Port Tube
Verical:
Conn D-Subminiature F 160 POS 1.27mm Solder RA Thru-Hole 160 Terminal 1 Port LFH™ Tube
