0805CS-181XGLC

0805CS-181XGLC 180nH/0.18UH 0805-R18G

值Inductance| 180nH/0.18UH \---|--- 误差Tolerance| ±2% 额定电流Current Rating| 400mA 饱和电流Current - Saturation| 不同频率时的Q值Q @ Frequency| 50 @ 250 MHz 自振谐频率SRFFrequency - Self Resonant| 920MHz DC电阻DCRDC Resistance DCR| 0.64Ω/Ohm 屏蔽Shielding| 无屏蔽 Unshielded Description & Applications| • Chip Inductors – 0805CS Series 2012 • Exceptional Q values, even at high frequencies • Tight tolerances – 2% for most; 1% for some values • Wirewound construction provides the highest SRFs in 0805 size 描述与应用| •片式电感 - 0805CS系列（2012） •特殊的Q值，即使在高频率 •严格的公差 - 2％为最多;一些值的1％ •线绕型电感提供了最高自振谐频率，0805尺寸
