3.00毫米（ 0.118 “ ）间距微飞度3.0 ， BMI插座头，双排，垂直，用压装的塑料钉， 2.54um 3.00mm .118" Pitch Micro-Fit 3.0, BMI Receptacle Header, Dual Row, Vertical, with Press-fit Plastic Pegs, 2.54um
12 位置 插座 0.118"（3.00mm） 通孔 锡
得捷:
CONN RCPT 12POS 0.118 TIN PCB
艾睿:
Thanks to Molex&s;s wire to board 0447691201 header connector, you can reduce the possibility of accidentally shorting out any pins on your printed circuit. This RCP connector&s;s 12 contacts that are made out of phosphor bronze and plated with tin over nickel. It has a receptacle type gender. This is a 2-row connector. It has a maximum voltage rating of 250 VAC. Its pitch is 3 mm. It has a straight body orientation. This device has a maximum current rating of 5 A/contact. The component will be shipped in tray format. It uses the solder termination method. 0447691201 is housed in black nylon 6/6. This product is 24 mm long, 13.6 mm tall and 8.4 mm deep. This connector has an operating temperature of -40 to 105 °C.
Verical:
Conn Wire to Board RCP 12 POS 3mm Solder ST Thru-Hole Tray
