2 A 5 VDC 通孔 通信/信号继电器
IM03TS=IM RELAY 140 MW 5 V
Product Highlights
IM Relay Series
DC Actuating System
Input Voltage = 5 VDC
Contact Arrangement = 2 Form C, DPDT, 2 C/O
Contact Current Rating = 2 Amps.
艾睿:
Signal Relay 5VDC 2A DPDT10x6x5.65mm THT Automotive
Jameco:
Electromechanical Relay Double Pole Double Throw 2A 5 Volt 178Ohm Through Hole
安富利:
Electromechanical Relay DPDT 2A 5VDC 178Ohm Through Hole
Chip1Stop:
Electromechanical Relay 5VDC 178Ohm 2A DPDT 10x6x5.65mm THT Signal Relay
TME:
Relay: electromagnetic; DPDT; Ucoil:5VDC; 0.5A/125VAC; 2A/30VDC
Verical:
Electromechanical Relay 5VDC 178Ohm 2A DPDT 10mm 6mm 5.65mm THT Signal Relay Automotive
MASTER:
IM-Relay Marking
Powell:
4G COM Relay IM
Online Components:
IM-Relay Marking
Electro Sonic:
IM03TS=IM RELAY 140 MW 5 V
Win Source:
RELAY TELECOM DPDT 2A 5V
触点电镀 Gold
额定电压DC 220 V
额定电压AC 250 V
绝缘电阻 >1000 MΩ
输入电压DC 5.00 V
触点类型 DPDT
接触电阻 50 mΩ
功耗 150 mW
触点额定电流 2 A
线圈电压 5 VDC
线圈电流 28.1 mA
线圈功率DC 140 mW
线圈电阻 178 Ω
载流 2.00 A
开关电流 2 A
额定电流Max 2 A
线圈电压DC 5 V
线圈功率 140 mW
额定功率Max 60W, 62.5VA
开关电流Max 2 A
工作温度Max 85 ℃
工作温度Min -40 ℃
额定电压DC Max 220 V
额定电压AC Max 250 V
接触电阻Max <50 mΩ
安装方式 Through Hole
引脚数 8
封装 DIP
长度 10 mm
宽度 6 mm
高度 5.65 mm
封装 DIP
触点材质 Palladium, Ruthenium, Gold
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tube
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ELV标准 Compliant
ECCN代码 EAR99
HTS代码 8536410030
