SR6 系列 24 V 8 A 六刀单掷 PC 插针 PCB 安装 强制导向 通用 继电器
V23050-A1024-A542
Product Highlights
Safety Relay SR6
V23050 Series
DC Actuating System
Contact Arrangement = 4 Form A & 2 Form B, 4PST-NO & DPST-NC, 4 N/O & 2 N/C
Contact Current Rating = 8 Amps.
得捷:
SR6B4024 - V23050-A1024-A542
立创商城:
V23050-A1024-A542
艾睿:
Electromechanical Relay 24VDC 480Ohm 8A 4PST-NO/DPST-NC 55x16.5x16.5mm THT Safety Relay
Chip1Stop:
Electromechanical Relay 24VDC 480Ohm 8A 4PST-NO/DPST-NC 55x16.5x16.5mm THT Safety Relay
TME:
Relay: electromagnetic; NC x2 + NO x4; Ucoil:24VDC; 8A; max400VAC
Verical:
Electromechanical Relay 24VDC 480Ohm 8A 4PST-NO/DPST-NC 55x16.5x16.5mm THT Safety Relay
MASTER:
Safety Relay - 24 VDC - 4PST-NO - DPST-NC - SR6 Series - Through Hole - 8 A - Solder.
Powell:
EMG Safety Relays
Online Components:
V23050-A1024-A542
Electro Sonic:
Safety Relay - 24 VDC - 4PST-NO - DPST-NC - SR6 Series - Through Hole - 8 A - Solder.
电源电压DC 24.0 V
额定电压DC 24.0 V
额定电压AC 400 V
额定电流 8.00 A
输入电压DC 24.0 V
触点类型 4PST
触点额定电流 8 A
线圈电压 24 VDC
线圈电流 50 mA
线圈功率DC 1.20 W
线圈电阻 480 Ω
额定电流Max 8 A
线圈电压DC 24 V
线圈功率 1.2 W
额定功率Max 2 KVA
安装方式 Through Hole
引脚数 14
封装 Through Hole
长度 55.0 mm
宽度 16.5 mm
高度 16.5 mm
封装 Through Hole
触点材质 Silver Tin Oxide
重量 30 g
工作温度 -25℃ ~ 70℃
产品生命周期 Active
包装方式 Box, Tube
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ELV标准 Compliant
REACH SVHC标准 No SVHC
ECCN代码 EAR99
HTS代码 8536410050
