Electromechanical Relay 24VDC 2.88KΩ 5A SPST-NO 20.39mm 7mm 15mm THT Industrial Relay
PCJ-124D3M-WG,000M
得捷:
PCJ-124D3M-WG 000M
贸泽:
General Purpose Relays 5A, 30VAC 1 Form ANO PCB MNT
艾睿:
Electromechanical Relay 24VDC 2.88KOhm 5A SPST-NO 20.39x7x15mm THT Industrial Relay
安富利:
Electromechanical Relay SPST-NO 5A 24VDC 2.88KOhm Through Hole
Chip1Stop:
Electromechanical Relay SPST-NO 5A 24VDC 2.88KOhm Through Hole
Verical:
Electromechanical Relay 24VDC 2.88KOhm 5A SPST-NO 20.39x7x15mm THT Industrial Relay
MASTER:
PCJ-WG,SPEC 000M CUSTOMER DRAWING
Online Components:
PCJ-124D3M-WG,000M
Electro Sonic:
PCJ-124D3M-WG,000M
Win Source:
PCJ-124D3M-WG 000M /
额定电压DC 30 V
额定电压AC 250 V
触点额定电流 5 A
线圈电压 24 VDC
线圈电流 8.33 mA
线圈电阻 2.88 KΩ
额定电流Max 5 A
线圈电压DC 24 V
额定功率Max 750 W
额定电压DC Max 30 V
额定电压AC Max 250 V
安装方式 Through Hole
引脚数 4
长度 20.39 mm
宽度 7 mm
高度 15 mm
触点材质 Silver Nickel
产品生命周期 Active
包装方式 Box
RoHS标准 RoHS Compliant
ELV标准 Compliant
ECCN代码 EAR99
HTS代码 8536490099
