PIN 二极管,ON Semiconductor多种 PIN 二极管,适用于射频开关和衰减器应用。### 标准带 NSV- 或 S- 前缀的制造商部件号符合 AEC-Q101 汽车等级。### 二极管和整流器,ON Semiconductor
PIN ,
多种 PIN 二极管,适用于射频开关和衰减器应用。
### 标准
带 NSV- 或 S- 前缀的制造商部件号符合 AEC-Q101 汽车等级。
得捷:
RF DIODE PIN 50V 100MW 3MCP
立创商城:
1SV249-TL-E
欧时:
ON Semiconductor 1SV249-TL-E PIN 二极管, Ifor=50mA, Vrev=50V, UHF,VHF, 3引脚 MCP封装, 使用于AGC
艾睿:
Creating a password for your user interface is easy with the 1SV249-TL-E PIN diode from ON Semiconductor. Its maximum power dissipation is 100 mW. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. This PIN diode attenuator has an operating temperature range of -55 °C to 125 °C. It is made in a dual series configuration.
Allied Electronics:
1SV249-TL-E Dual Series PIN Diode, 50mA, 50V, 3-Pin MCP
安富利:
Diode PIN 50V 3-Pin MCP T/R
Verical:
PIN Diode 50V 50mA 3-Pin SC-70 T/R
正向电压 920 mV
耗散功率 100 mW
正向电流 50 mA
正向电压Max 920 mV
正向电流Max 50 mA
工作温度Max 125 ℃
工作温度Min -55 ℃
耗散功率Max 100 mW
安装方式 Surface Mount
引脚数 3
封装 SOT-323
长度 2 mm
宽度 1.25 mm
高度 0.9 mm
封装 SOT-323
工作温度 125℃ TJ
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
香港进出口证 NLR
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
1SV249-TL-E ON Semiconductor 安森美 | 当前型号 | 当前型号 |
