1571999-1

2 位置 单刀单掷 侧面驱动 未密封 2.54 mm 间距 通孔 DIP 开关

琴键式执行器

高压摩擦触点可用水或溶液清洁，无需胶带密封

可耐汽相回流焊接或波焊条件

触点电阻：50mΩ

### 注

除非另有说明，否则这些开关不适于浸泡清洗。

欧时:
DIP switch,PCB,SPST,2 positions,piano

立创商城:
1571999-1

艾睿:
The 1571999-1 dual in-line package switch, developed by TE Connectivity, can give you electronic flow control within your printed circuit board. This device has a maximum current rating of 0.1 A @ 24VDC. It has a SPST configuration. This DIP switch has a minimum operating temperature of -30 °C and a maximum of 85 °C. The 1571999-1 DIP switch has a PC pin termination style. This product is 7.06 mm long, 7.3 mm tall and 10.25 mm deep. The maximum DC voltage rating is 24 VDC. This product&s;s terminal pitch is 2.54 mm.

Chip1Stop:
Switch DIP OFF ON SPST 2 Piano 0.1A 24VDC PC Pins 2.54mm Thru-Hole Tube

Verical:
Switch DIP OFF ON SPST 2 Piano 0.1A 24VDC PC Pins 2.54mm Thru-Hole Box/Tube

MASTER:
DIP SWITCH ASSEMBLY ADP/PA SERIES

Powell:
DIP, Rotary DIP, SIP Switches and DIP Shunts - Standard

Online Components:
ADP0204=PIANO DIP SWITCH

Electro Sonic:
ADP0204=PIANO DIP SWITCH
