TE Connectivity 微型按钮开关, 3 A A @ 125 V 交流 黑色/绿色/红色 On-On 双刀双掷 面板安装
面板安装微型按钮 - MPS 系列
MPS 系列面板安装微型按钮，带咬接式机制和黄铜镀金单刀双掷 MPS1 或双刀双掷 MPS2 先断后合触点，30 V 直流时额定电流为 60mA。 这些 MPS 系列微型按钮具有黄铜镀镍 8mm 扩展执行器，带开-开或接通-（接通）切换功能和 1/4-40 螺纹衬套，并提供印刷电路板安装引脚或接线片。
单独提供黑色、绿色或红色盖 - 请参见必备附件
欧时:
Pushbutton switch DPDT OnOn MPS series
艾睿:
Turn on and off portions of your circuit design with the aid of this 1977739-4 push button switch manufactured from TE Connectivity. This device has a maximum current rating of 3 A @ 125VAC. It has a DPDT configuration. This push switch has an operating temperature range of -20 °C to 80 °C. The 1977739-4 push switch has a wire lug termination style. This product is 13 mm long, 31 mm tall and 13 mm deep. The maximum AC voltage rating is 125 VAC.
Verical:
Switch Push Button ON ON DPDT Plunger 3A 125VAC Momentary Contact Wire Lug Panel Mount Medical Loose
MASTER:
MPS203R PSHBTTN DPDT MMNTRY
Powell:
MPS203R PSHBTTN DPDT MMNTRY
Online Components:
MPS203R PSHBTTN DPDT MMNTRY
Electro Sonic:
MPS203R PSHBTTN DPDT MMNTRY
