1571982-7

2 位置 双刀双掷 极-掷 顶部 黑色

滑动 DPDT 通孔

艾睿:
Using the 1571982-7 slide switch from TE Connectivity is the best way to turn your circuit on or off. It has a DPDT configuration. This slide switch has an operating temperature range of -20 °C to 80 °C. The 1571982-7 slide switch has a PC pin termination style. This product comes packaged in bulk, so the parts will be stored loosely. The maximum AC voltage rating is 20 VAC and the maximum DC voltage rating is 20 VDC. This product is 10.16 mm long, 12.85 mm tall and 9.14 mm deep.

安富利:
Switch Slide ON None ON DPDT Extended Top Slide 20VAC 20VDC 0.4VA PC Pins Thru-Hole Bulk

Chip1Stop:
Switch Slide ON None ON DPDT Extended Top Slide 20VAC 20VDC 0.4VA PC Pins Thru-Hole Bulk

Verical:
Switch Slide ON None ON DPDT Extended Top Slide 20VAC 20VDC 0.4VA PC Pins Thru-Hole Bulk

MASTER:
SLIDE SWITCH TSS11 AND TSS21 SERIES

Powell:
Slide Switches

Online Components:
TSS21NGPC04=SLIDE SWITCH DPDT

Electro Sonic:
TSS21NGPC04=SLIDE SWITCH DPDT
