DO-35 33V 0.5W1/2W
Zener Diode 33V 500mW ±5% Through Hole DO-35
得捷:
DIODE ZENER 33V 500MW DO35
艾睿:
This 1N5257B-TP zener diode from Micro Commercial Components will allow you to run it in the reverse direction. Its maximum power dissipation is 500 mW. Its maximum leakage current is 0.1 μA. Its test current is 3.8 mA. In order to guarantee safe delivery and allow for quick mounting of this component after delivery, it will be enclosed in tape and reel packaging during shipment. This zener diode has an operating temperature range of -55 °C to 150 °C. This zener device has a nominal voltage of 33 V and a voltage tolerance of 5%. It is made in a single configuration.
Chip1Stop:
Diode Zener Single 33V 5% 500mW 2-Pin DO-35 T/R
Win Source:
DIODE ZENER 33V 500MW DO35
额定电压DC 33.0 V
容差 ±5 %
额定功率 500 mW
正向电压 1.1V @200mA
耗散功率 500 mW
测试电流 3.8 mA
稳压值 33 V
正向电压Max 1.1V @200mA
额定功率Max 500 mW
工作温度Max 150 ℃
工作温度Min -55 ℃
耗散功率Max 500 mW
安装方式 Through Hole
引脚数 2
封装 DO-35
长度 4.2 mm
宽度 2 mm
高度 2 mm
封装 DO-35
工作温度 -55℃ ~ 150℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 无铅
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
1N5257B-TP Micro Commercial Components 美微科 | 当前型号 | 当前型号 |
1N5257B-A 美台 | 类似代替 | 1N5257B-TP和1N5257B-A的区别 |
1N5257B-T 美台 | 功能相似 | 1N5257B-TP和1N5257B-T的区别 |
1N5257B 意法半导体 | 功能相似 | 1N5257B-TP和1N5257B的区别 |
