17230552102

Conn Hard Metric F 55POS 2mm Press Fit RA Thru-Hole

har-bus® HM connectors form the basis for the assembly of high-performance backplanes for control systems and for industrial computer systems with 19 inch technology. The board-to-board connectors are available with press-in technology for backplanes and solder versions for sub-boards.

欧时:
har-bus HM,2mm,Female,Type C, 55 way

得捷:
CONN RECEPT 55POS 2MM PRESS-FIT

立创商城:
17230552102

艾睿:
The Harting hard metric 17230552102 backplane connector can help you connect multiple different lines in parallel, essentially forming a computer bus for your project. This F connector has 55 contacts that are plated with gold over nickel. It has a female type gender. Its pitch is 2 mm. This is a 5-row connector. It has a right angle body orientation. This product is 24.9 mm long, 12.2 mm tall and 22.45 mm deep. It uses the press fit termination method.

Allied Electronics:
har-bus HM Federl. Typ-C m. Schirmbl.

Verical:
Conn Hard Metric F 55 POS 2mm Press Fit RA Thru-Hole Tube

Newark:
# HARTING  17230552102  Connector, har-bus HM Series, Hard Metric HM, 55 Contacts, Receptacle, 2 mm, Press Fit
