3W,1N59xxB 系列 Surmetic™,On Semiconductor### Zener Diodes, ON Semiconductor
齐纳 3W,1N59xxB 系列 Surmetic™,On Semiconductor
欧时:
### 齐纳二极管 3W,1N59xxB 系列 Surmetic™,On Semiconductor### Zener Diodes, ON Semiconductor
得捷:
DIODE ZENER 8.2V 3W AXIAL
立创商城:
1N5923BRLG
贸泽:
稳压二极管 8.2V 3W
e络盟:
单管二极管 齐纳, 8.2 V, 3 W, DO-41 DO-204AL, 5 %, 2 引脚, 200 °C
艾睿:
Need to operate a diode in the reverse-breakdown region? No worries, use a voltage regulator 1N5923BRLG zener diode from ON Semiconductor. Its maximum leakage current is 5 μA. Its maximum power dissipation is 3000 mW. Its test current is 45.7 mA. This device has a maximum regulator current of 182 mA. This component will be shipped in tape and reel packaging for effective mounting and safe delivery. This zener diode has a minimum operating temperature of -65 °C and a maximum of 200 °C. It is made in a single configuration. This zener device has a nominal voltage of 8.2 V and a voltage tolerance of 5%.
Allied Electronics:
1N5923BRLG Zener Diode, 8.2V 5% 3 W Through Hole 2-Pin Case 59-10
安富利:
Diode Zener Single 8.2V 5% 3W 2-Pin DO-41 T/R
Chip1Stop:
Diode Zener Single 8.2V 5% 3W 2-Pin DO-41 T/R
Verical:
Zener Diode Single 8.2V 5% 3.5Ohm 3000mW 2-Pin DO-41 T/R
罗切斯特:
Diode Zener Single 8.2V 5% 3W 2-Pin DO-41 T/R
Win Source:
DIODE ZENER 8.2V 3W AXIAL
额定电压DC 6.20 V
容差 ±5 %
额定功率 3.00 W
无卤素状态 Halogen Free
针脚数 2
正向电压 1.5V @200mA
耗散功率 3 W
测试电流 45.7 mA
稳压值 8.2 V
正向电压Max 1.5V @200mA
额定功率Max 3 W
工作温度Max 200 ℃
工作温度Min -65 ℃
耗散功率Max 3 W
安装方式 Through Hole
引脚数 2
封装 DO-41-2
长度 5.2 mm
宽度 2.7 mm
高度 2.7 mm
封装 DO-41-2
工作温度 -65℃ ~ 200℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
1N5923BRLG ON Semiconductor 安森美 | 当前型号 | 当前型号 |
1N5923B 安森美 | 类似代替 | 1N5923BRLG和1N5923B的区别 |
BZV85-C8V2,133 恩智浦 | 功能相似 | 1N5923BRLG和BZV85-C8V2,133的区别 |
BZX85C8V2 安森美 | 功能相似 | 1N5923BRLG和BZX85C8V2的区别 |
