12065A4R3CAT2A

12065A4R3CAT2A图片1
12065A4R3CAT2A图片2
12065A4R3CAT2A图片3
12065A4R3CAT2A图片4
12065A4R3CAT2A图片5
12065A4R3CAT2A概述

1206 4.3pF ±0.25pF 50V C0G

4.3 pF ±0.25pF 50V 陶瓷器 C0G,NP0 1206(3216 公制)


得捷:
CAP CER 4.3PF 50V NP0 1206


艾睿:
Cap Ceramic 4.3pF 50V C0G 0.25pF SMD 1206 125


安富利:
C0G NP0 is the most popular formulation of the “temperature-compensating,” EIA Class I ceramic materials. Modern C0G NP0 formulations contain neodymium, samarium and other rare earth oxides.


12065A4R3CAT2A中文资料参数规格
技术参数

额定电压DC 50.0 V

电容 4.30 pF

容差 ±0.25 pF

电介质特性 C0G/NP0

额定电压 50 V

封装参数

安装方式 Surface Mount

封装公制 3216

封装 1206

外形尺寸

长度 3.2 mm

宽度 1.6 mm

封装公制 3216

封装 1206

物理参数

材质 C0G/-55℃~+125℃

工作温度 -55℃ ~ 125℃

其他

产品生命周期 Active

包装方式 Tape

最小包装 2000

制造应用 通用

符合标准

RoHS标准 RoHS Compliant

含铅标准 Lead Free

数据手册

在线购买12065A4R3CAT2A
型号: 12065A4R3CAT2A
制造商: AVX 艾维克斯
描述:1206 4.3pF ±0.25pF 50V C0G
