1.5KE75A-B

瞬态电压抑制二极管 Transient Voltage Suppression Diodes

Description

The 1.5KE Series is designed specifically to protect sensitive electronic equipment from voltage transients induced by lightning and other transient voltage events.

得捷:
TVS DIODE 64.1VWM 103VC DO201

立创商城:
单向 Vrwm:64.1V 1.5kW

艾睿:
Prevent your circuits from experiencing malfunctions from electrostatic discharge with this 1.5KE75A-B TVS diode from Littelfuse. This device&s;s maximum clamping voltage is 103 V and minimum breakdown voltage is 71.3 V. Its peak pulse power dissipation is 1500 W. Its test current is 1 mA. Its maximum leakage current is 1 μA. This TVS diode has an operating temperature range of -55 °C to 175 °C. This product comes packaged in bulk, so the parts will be stored loosely.

Chip1Stop:
Diode TVS Single Uni-Dir 64.1V 1.5KW 2-Pin DO-201 Bulk

TME:
Diode: transil; 1.5kW; 75V; 14.8A; unidirectional; ±5%; DO201
