1.5KE110A

硅雪崩二极管 - 1500瓦的轴向引线型瞬态电压抑制器 Silicon Avalanche Diodes - 1500 Watt Axial Leaded Transient Voltage Suppressors

Transient Voltage Suppression Diodes

Axial Leaded – 1500W > 1.5KE series

Description

The 1.5KE Series is designed specifically to protect sensitive electronic equipment from voltage transients induced by lightning and other transient voltage events.

得捷:
TVS DIODE 94VWM 152VC DO201

立创商城:
单向 Vrwm:94V

贸泽:
ESD Suppressors / TVS Diodes 1500W 94V Uni-Directional

艾睿:
Sleep easy, never worry about surges again with this 1.5KE110A TVS diode from Littelfuse. This device&s;s maximum clamping voltage is 152 V and minimum breakdown voltage is 105 V. Its test current is 1 mA. Its maximum leakage current is 1 μA. Its peak pulse power dissipation is 1500 W. This TVS diode has a minimum operating temperature of -55 °C and a maximum of 175 °C. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery.

Chip1Stop:
Diode TVS Single Uni-Dir 94V 1.5KW 2-Pin DO-201 T/R

TME:
Diode: transil; 1.5kW; 110V; 10A; unidirectional; ±5%; DO201

Verical:
TVS Diode Single Uni-Dir 94V 1.5KW 2-Pin DO-201 T/R

Win Source:
TVS DIODE 94VWM 152VC AXIAL
