JOHANSON DIELECTRICS 101X14W221MV4T 多层陶瓷电容器, 表面贴装, X2Y系列, 220 pF, ± 20%, X7R, 100 V, 0603 [1608 公制]
This multilayer ceramic capacitor from Johanson can be used in multiple applications and for various purposes. It can withstand a voltage of 100 VDC. This MLCC capacitor has a maximum operating temperature of 125 °C. This component will be shipped in tape and reel packaging for effective mounting and safe delivery. It has a tolerance of 20%. This device is made with x2y technology. This product is 1.626 mm long, 0.66Max mm tall and 0.889 mm deep. Its capacitance value is 220pF.
额定电压DC 100 V
电容 220 pF
容差 ±20 %
电介质特性 X7R
工作温度Max 125 ℃
工作温度Min -55 ℃
额定电压 100 V
安装方式 Surface Mount
引脚数 4
封装公制 1608
封装 0603
长度 1.6 mm
宽度 0.8 mm
高度 0.66 mm
封装公制 1608
封装 0603
工作温度 -55℃ ~ 125℃
产品生命周期 Active
包装方式 Cut Tape CT
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/12/17
ECCN代码 EAR99
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
101X14W221MV4T Johanson Technology 约翰逊 | 当前型号 | 当前型号 |
MCSH18B221K101CT Multicomp | 功能相似 | 101X14W221MV4T和MCSH18B221K101CT的区别 |
