1991118

认可UL/CUL

认可

UL/CUL

欧时:
Phoenix Contact COMBICON SPT 系列 5mm 节距 4 路 直向 印刷电路板接线端子块 1991118, 通孔

得捷:
TERM BLK 4POS TOP ENTRY 5MM PCB

贸泽:
Fixed Terminal Blocks SPT 2.5/ 4-V-5.0 5MM 4P VERT SPR

艾睿:
Get the best connections between your circuits with this spring cage 1991118 PCB terminal block from Phoenix Contact. It has a maximum voltage rating of 250 V. This is a 1-row connector. Its pitch is 5 mm. It has a straight body orientation. This device has a maximum current rating of 24 A. 1991118 is housed in polyamide. It uses the solder termination method. Its wire is 12-24 AWG. This product is 21.4 mm long, 14.4 mm tall and 13.5 mm deep.

Allied Electronics:
Conn; Term Blk; PCB; Spring Cage; 4; 5 mm; Top; 24-12 AWG; Green; 24 A; 250 V

Verical:
Conn pC Terminal Block 4 Pos 5mm Solder St Thru-Hole 24A Cardboard

MASTER:
PCB terminal block - nominal current: 24 A - rated voltage III/2: 400 V - nominal cross section: 2.5 mm² - pitch: 5 mm - number of positions: 4 - connection method: Push-in spring connection - mounting: Wave soldering - conductor/PCB connection directio

Online Components:
Conn Spring Cage 4 POS 5mm Solder ST Thru-Hole 24A

Electro Sonic:
PCB terminal block - nominal current: 24 A - rated voltage III/2: 400 V - nominal cross section: 2.5 mm² ...
