1733583

PHOENIX CONTACT  1733583  线至板接线端子, 3 路, 300 V, 10 A, 26 AWG, 14 AWG, 2.5 mm²

Contact COMBICON SMKDSP 5.08mm 斜角印刷电路板端子块

斜角印刷电路板端子板，允许一些端子排在彼此背后进行排列

5.08mm 节距

### 注

薄型 55° 入口类型为边层叠式，但是将丢失节距连续性。

### 认可

UL E60425; CSA LR13631

得捷:
TERM BLOCK 3POS 55DEG 5.08MM PCB

欧时:
Phoenix Contact SMKDSP 系列 1733583 3 路 无熔丝端子块, 通孔, 焊接端接, 30 → 14 AWG线规格, 22A

立创商城:
5.08mm 排数:1 每排P数:3 直针 可拼接

e络盟:
线至板接线端子, 3 路, 300 V, 10 A, 26 AWG, 14 AWG, 2.5 mm²

艾睿:
This pc terminal block 1733583 PCB terminal block manufactured from Phoenix Contact will bridge different sections of wires together. This is a 1-row connector. Its pitch is 5.08 mm. It has a maximum voltage rating of 250 V. This device has a maximum current rating of 22 A. 1733583 is housed in polyamide. It uses the solder termination method. This product is 15.24 mm long, 15.3 mm tall and 13.4 mm deep. Its wire is 14-26 AWG.

Allied Electronics:
Conn; Term Blk; PCB; 3 Position; 30 to 14 AWG; 400 V; 17.5 A

Verical:
Conn PC Terminal Block 3 POS 5.08mm Solder Thru-Hole 17.5A

Newark:
# PHOENIX CONTACT  1733583  Wire-To-Board Terminal Block, 5.08 mm, 3 Positions, 26 AWG, 14 AWG, 2.5 mm², Screw

MASTER:
PCB terminal block - nominal current: 17.5 A - rated voltage III/2: 400 V - nominal cross section: 1.5 mm² - pitch: 5.08 mm - number of positions: 3 - connection method: Screw connection with tension sleeve - mounting: Wave soldering - conductor/PCB con

Online Components:
Conn PC Terminal Block 3 POS 5.08mm Solder Thru-Hole 22A

Electro Sonic:
PCB terminal block - nominal current: 17.5 A - rated voltage III/2: 400 V - nominal cross section: 1.5 mm² ...
