1729018

Phoenix Contact COMBICON MKDSN 5.0mm 薄型印刷电路板端子块Professional range of Phoenix Contact MKDSN Series 5.0 mm pitch terminal blocks offering various different positions.Various positions available 5.0 mm pitch Colour: Green ### Phoenix Contact COMBICON 5.0mm 印刷电路板端子块

Contact COMBICON MKDSN 5.0mm 薄型印刷电路板端子块

Professional range of Phoenix Contact MKDSN Series 5.0 mm pitch terminal blocks offering various different positions.

Various positions available

5.0 mm pitch

Colour: Green

### Phoenix Contact COMBICON 5.0mm 印刷电路板端子块

得捷:
TERM BLK 2POS SIDE ENTRY 5MM PCB

欧时:
Low profile PCB terminal block,5mm,2 way

立创商城:
5mm 排数:1 每排P数:2

艾睿:
Connecting one or more circuits together, this pc terminal block 1729018 PCB terminal block from Phoenix Contact is a must-have! Its pitch is 5 mm. It has a straight body orientation. It has a maximum voltage rating of 400 V. This is a 1-row connector. 1729018 is housed in polyamide. This device has a maximum current rating of 13.5 A. It uses the solder termination method. This product is 10 mm long, 10 mm tall and 8.1 mm deep. Its wire is 16-26 AWG.

Allied Electronics:
Conn; Term Blk; PCB; Screw; 2; 5 mm; Front; 26-16 AWG; 13.5 A; 250 V; Solder

富昌:
CONN TERM BLOCK 2POS 5MM PCB

Verical:
Conn PC Terminal Block 2 POS 5mm Solder ST Thru-Hole 13.5A Cardboard

MASTER:
PCB terminal block - nominal current: 13.5 A - rated voltage III/2: 400 V - nominal cross section: 1.5 mm² - pitch: 5 mm - number of positions: 2 - connection method: Screw connection with tension sleeve - mounting: Wave soldering - conductor/PCB connec

Online Components:
Conn PC Terminal Block 2 POS 5mm Solder ST Thru-Hole 13.5A

Electro Sonic:
PCB terminal block - nominal current: 13.5 A - rated voltage III/2: 400 V - nominal cross section: 1.5 mm² ...
