1041880210

插座

SSL Connector 2 Position Receptacle, Poke-In Wire Board to Cable/Wire 0.157" 4.00mm Solder

立创商城:
4mm 每排P数:2 排数:1 照明连接器

得捷:
CONN SSL RCPT 2POS 4MM SOLDER

艾睿:
Are you looking for a solution to support physical configuration options on your PCB? Then mount this wire to board 1041880210 header connector from Molex on your PCB today! This F connector&s;s 2 contacts that are made out of copper alloy and plated with tin. It has a right angle body orientation. It has a female type gender. This is a 1-row connector. It has a maximum voltage rating of 300 V. Its pitch is 4 mm. This device has a maximum current rating of 9 A/contact. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. 1041880210 is housed in white liquid crystal polymer. This product is 7.9 mm long, 4.2 mm tall and 13 mm deep. This connector has an operating temperature of -40 to 130 °C. It uses the solder termination method.

安富利:
Conn Wire to Board RCP 2 POS 4mm Solder ST SMD Tray

Chip1Stop:
Conn Wire to Board F 2 POS 4mm Solder RA SMD Lite-Trap™ Embossed T/R

TME:
Connector: plug-in; Lite-Trap; 4mm; ways:2; 24÷18AWG; tinned; 9A

Verical:
Conn Wire to Board F 2 POS 4mm Solder RA SMD Lite-Trap™ T/R

儒卓力:
**2P LITE TRAP SMT WTB PUSH BUTT **
