肖特基二极管与整流器 Vr/30V Io/3A T/R
Diode Schottky 30 V 3A Through Hole DO-201AD
得捷:
DIODE SCHOTTKY 30V 3A DO201AD
贸泽:
肖特基二极管与整流器 Vr/30V Io/3A T/R
艾睿:
If your circuit needs to adjust from an AC to DC voltage use a Schottky diode 1N5821RL rectifier from STMicroelectronics. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. Its peak non-repetitive surge current is 80 A, while its maximum continuous forward current is 3 A. It is made in a single configuration. This rectifier has an operating temperature range of -65 °C to 150 °C.
Verical:
Diode Schottky 30V 3A 2-Pin DO-201AD T/R
额定电压DC 30.0 V
额定电流 3.00 A
输出电流 ≤3.00 A
正向电压 500mV @3A
极性 Standard
最大正向浪涌电流(Ifsm) 80 A
正向电压Max 500mV @3A
正向电流Max 3 A
工作温度Max 150 ℃
工作温度Min -65 ℃
工作结温 150℃ Max
安装方式 Through Hole
引脚数 2
封装 DO-201AD
长度 9.5 mm
宽度 5.3 mm
高度 5.3 mm
封装 DO-201AD
产品生命周期 Obsolete
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
1N5821RL ST Microelectronics 意法半导体 | 当前型号 | 当前型号 |
1N5821-T 美台 | 完全替代 | 1N5821RL和1N5821-T的区别 |
1N5821G 安森美 | 功能相似 | 1N5821RL和1N5821G的区别 |
1N5821RLG 安森美 | 功能相似 | 1N5821RL和1N5821RLG的区别 |
