Illuminated Pushbutton Switches 30mm 5A 125VAC GN
Both the housing and the actuator of the vandal-proof MSM switch are made of high-quality stainless steel. By applying this robust and weather-resistant material, the switch is particularly suitable for use in harsh environments.
立创商城:
1241.6663.1122000
贸泽:
Illuminated Pushbutton Switches 30mm 5A 125VAC GN
Allied Electronics:
Switch; PB; Metal; Md Strk; Mmntry; 30mm; SPDT; 125/250VAC; 5/3A; Steel; Pnt Illu-Grn; IP40
安富利:
MSM30 PI SF 5 A @125VAC GN
Chip1Stop:
Switch Push Button N.O./N.C. SPDT Flush Round Button 5A 250VAC Quick Connect Panel Mount Box
Electro Sonic:
MSM30 PI SF 5 A @125VAC GN
CDI:
MSM30 PI SF 5 A @125VAC GN
触点电镀 Silver
额定电压AC 250 V
额定电流 5 A
触点类型 SPDT
触点额定电流 5.00 A
工作温度Max 85 ℃
工作温度Min -25 ℃
额定电压 125 VAC
电源电压Max 250 V
电源电压Min 5 V
安装方式 Through Hole
封装 -
长度 36 mm
高度 35.15 mm
封装 -
触点材质 Silver
工作温度 -25℃ ~ 85℃
外壳材质 Stainless Steel
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2016/06/20
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
1241.6663.1122000 Schurter | 当前型号 | 当前型号 |
1241.6663.1121000 Schurter | 完全替代 | 1241.6663.1122000和1241.6663.1121000的区别 |
