14020615101000

6 位置 单排 16-30 AWG Har-Flexicon 3.81 TTPV-6 TB50 BK 连接器

har-flexicon® - The connection of PCBs shows a clear trend towards the miniaturization and reflow-soldering connection technology. This requires innovative answers regarding size, utilization, flexibility, and handling of the components.

The har-flexicon® product family has been designed for the toolless connection of single wires and the SMT/SMC-reflow-soldering process. har-flexicon® ensures an efficient processing for both the device production and the device installation.

得捷:
TERM BLK 6POS TOP ENT 3.81MM PCB

贸泽:
Fixed Terminal Blocks 6P 30-16 AWG spring 300V 10A 3.81mm THR

艾睿:
Connect test equipment together with other components by using this 14020615101000 PCB terminal block from Harting. This is a 1-row connector. Its pitch is 3.81 mm. It has a straight body orientation. It has a maximum voltage rating of 300 V. 14020615101000 is housed in polyamide/polyphthalamide. This device has a maximum current rating of 10 A. It uses the solder termination method. This quick disconnect terminal has an operating temperature of -40 to 110 °C. This product is 14.85 mm tall. Its wire is 16-30 AWG.

Allied Electronics:
Conn.; Terminal Block; PCB; 3.81mm Pitch; Vertical; 6 Pin; TB50; Black; har-flexicon

Verical:
Conn Terminal Block 6 POS 3.81mm Spring Clamp ST Thru-Hole 10A har-flexicon® Bulk

Newark:
# HARTING  14020615101000  Wire-To-Board Terminal Block, 3.81 mm, 6 Positions, 30 AWG, 16 AWG, 1.5 mm², Push In
