8 位置 单排 16-30 AWG Har-Flexicon 3.50 TTPV-8 TB50 BK 连接器
har-flexicon® - The connection of PCBs shows a clear trend towards the miniaturization and reflow-soldering connection technology. This requires innovative answers regarding size, utilization, flexibility, and handling of the components.
The har-flexicon® product family has been designed for the toolless connection of single wires and the SMT/SMC-reflow-soldering process. har-flexicon® ensures an efficient processing for both the device production and the device installation.
得捷:
TERM BLK 8P TOP ENTRY 3.5MM PCB
e络盟:
TERMINAL BLOCK, PCB, 8WAY, 30-16AWG, HAR
艾睿:
Conn Terminal Block 8 POS 3.5mm Spring Clamp ST Thru-Hole 10A har-flexicon® Bulk
Allied Electronics:
Conn.; Terminal Block; PCB; 3.50mm Pitch; Vertical; 8 Pin; TB50; Black; har-flexicon
Verical:
Conn Terminal Block 8 POS 3.5mm Spring Clamp ST Thru-Hole 10A har-flexicon® Bulk
Newark:
# HARTING 14020814101000 Wire-To-Board Terminal Block, 3.5 mm, 8 Positions, 30 AWG, 16 AWG, 1.5 mm², Push In
触点数 8
线规 16AWG ~ 30AWG
触点电镀 Tin
额定电流 10 A
绝缘电阻 10 GΩ
排数 1
电路数 8
针脚数 8
接触电阻 15 mΩ
额定电流Max 10 A
额定电压Max 300 V
额定电压 300 V
工作电压Max 300 V
安装方式 Through Hole
长度 28 mm
高度 14.85 mm
外壳颜色 Black
颜色 Black
触点材质 Copper
工作温度 -40℃ ~ 110℃
产品生命周期 Active
包装方式 Bulk
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/12/17
