Conn Spring Cage 7POS 5mm Solder ST Thru-Hole 24A
Conn Spring Cage 7 POS 5mm Solder ST Thru-Hole 24A
得捷:
TERM BLK 7POS TOP ENTRY 5MM PCB
艾睿:
This spring cage 1991147 PCB terminal block manufactured from Phoenix Contact will connect wires together. It has a straight body orientation. It has a maximum voltage rating of 250 V. Its pitch is 5 mm. This is a 1-row connector. 1991147 is housed in polyamide. This device has a maximum current rating of 24 A. Its wire is 12-24 AWG. It uses the solder termination method. This product is 36.4 mm long, 14.4 mm tall and 13.5 mm deep.
Allied Electronics:
COMBICON SPT SER 5mm Pitch Straight PCBTrm Blk w/ Spring Cage Term, Through Hole
Verical:
Conn PC Terminal Block 7 POS 5mm Solder ST Thru-Hole 24A
MASTER:
PCB terminal block - nominal current: 24 A - rated voltage III/2: 400 V - nominal cross section: 2.5 mm² - pitch: 5 mm - number of positions: 7 - connection method: Push-in spring connection - mounting: Wave soldering - conductor/PCB connection directio
Online Components:
Conn Spring Cage 7 POS 5mm Solder ST Thru-Hole 24A
Electro Sonic:
PCB terminal block - nominal current: 24 A - rated voltage III/2: 400 V - nominal cross section: 2.5 mm² ...
