Conn PC Terminal Block F 6POS 5.08mm Solder Thru-Hole 12A
接线板 - 线至板
得捷:
TERM BLOCK 6POS 45DEG 5.08MM PCB
欧时:
PCB terminal block,5.08mm, 6 way, 45 deg
艾睿:
Phoenix Contact&s;s pc terminal block 1791884 PCB terminal block will ensure strong connections between circuits. This F connector has 6 F contacts. It has a female type gender. Its pitch is 5.08 mm. It has a maximum voltage rating of 250 V. This is a 1-row connector. 1791884 is housed in polyamide. This device has a maximum current rating of 12 A. It uses the solder termination method. Its wire is 16-24 AWG. This product is 30.48 mm long, 12.8 mm tall and 16.2 mm deep.
Allied Electronics:
COMBICON MFKDSP Series 5.08mm Pitch Right Angle PCB Trm Blk w/ Spring Cage Term
MASTER:
PCB terminal block - nominal current: 12 A - rated voltage III/2: 320 V - nominal cross section: 1 mm² - pitch: 5.08 mm - number of positions: 6 - connection method: Push-in spring connection - mounting: Wave soldering - conductor/PCB connection directi
Online Components:
Conn PC Terminal Block F 6 POS 5.08mm Solder Thru-Hole 12A
Electro Sonic:
PCB terminal block - nominal current: 12 A - rated voltage III/2: 320 V - nominal cross section: 1 mm² ...
