1700053

2.5mm 导线 允许轻松通过面板开孔 额定值 24A/320V 5.08 mm 节距 温度额定值：-40°C 至 120°C ### 认可UL E60425; CSA LR13631 ### Phoenix Contact COMBICON 10mm 印刷电路板端子块

正面安装接线板

适用于如下应用，如电源或仪器仪表，以及控制或印刷电路板安装需要正面连接的任何地方。 端盖是用来密封端子的终端。

接受 2.5mm 导线

允许轻松通过面板开孔

额定值 24A/320V

5.08 mm 节距

温度额定值：-40°C 至 120°C

### 认可

UL E60425; CSA LR13631

得捷:
TERM BLK 1POS TOP ENTRY PCB 10PC

欧时:
Phoenix Contact COMBICON FRONT 系列 5mm 节距 2 行 1 路 绿色 直向 印刷电路板接线端子块 1700053

贸泽:
Fixed Terminal Blocks FRONT 2 5-V/SA10

艾睿:
Create a bridge between two sides of a circuit by implementing this 1700053 PCB terminal block from Phoenix Contact. It has a maximum voltage rating of 400 V. It has a right angle body orientation. This is a 1-row connector. 1700053 is housed in polyamide. This device has a maximum current rating of 24 A. Its wire is 14-24 AWG. This product is 5 mm long, 19.5 mm tall and 18.5 mm deep. It uses the solder termination method.

Allied Electronics:
Front entry vertical terminal, 10mm pitch

Verical:
Conn PC Terminal Block 1 POS Solder RA Thru-Hole 24A Cardboard

Electro Sonic:
PCB terminal block - nominal current: 24 A - rated voltage III/2: 400 V - nominal cross section: 2.5 mm² ...
