DIP, Rotary DIP, SIP Switches and DIP Shunts - Standard
GDS0604=DIP SW,SLIDE,THRU/HL
Product Highlights
Switch - Mechanical
Switch Type = DIP
PCB Mount Style = Through Hole
Single Pole - Single Throw Configuration Pole-Throw
Actuator Style = Slide
艾睿:
Switch DIP OFF ON SPST 6 Flush Slide 0.025A 24VDC PC Pins 2.54mm Thru-Hole Tube
安富利:
Switch DIP ON OFF SPST 6 Flush Slide 0.025A 24VDC PC Pins 2.54mm Thru-Hole T/R
Chip1Stop:
Switch DIP ON OFF SPST 6 Flush Slide 0.025A 24VDC PC Pins 2.54mm Thru-Hole T/R
Verical:
Switch DIP OFF ON SPST 6 Flush Slide 0.025A 24VDC PC Pins 2.54mm Thru-Hole Tube
MASTER:
DIP SWITCH ASSEMBLY GDS SERIES
Powell:
DIP, Rotary DIP, SIP Switches and DIP Shunts - Standard
Online Components:
GDS0604=DIP SW,SLIDE,THRU/HL
Electro Sonic:
GDS0604=DIP SW,SLIDE,THRU/HL
触点电镀 Gold, Gold over Nickel
额定电压DC 24 V
额定电流 25 mA
触点类型 SPST
易燃性等级 UL 94 V-0
针脚数 6
额定电流Max 0.025A @24VDC
工作温度Max 100 ℃
工作温度Min -40 ℃
额定电压 24 VDC
额定电压DC Max 24 V
接触电阻Max 100 mΩ
安装方式 Through Hole
长度 15.1 mm
高度 2.7 mm
外壳颜色 Black
触点材质 Copper Alloy
工作温度 -40℃ ~ 100℃
产品生命周期 Active
包装方式 Tube
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ELV标准 Compliant
ECCN代码 EAR99
HTS代码 8536509032
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
1825006-9 TE Connectivity 泰科 | 当前型号 | 当前型号 |
GDS06 泰科 | 功能相似 | 1825006-9和GDS06的区别 |
