Conn Housing RCP 18POS 2.54mm Crimp ST Cable Mount
18 MODIV HSG COMP DR .100CL
Product Highlights
Housing
Not Preloaded
Number of Positions = 18
Housing Type = Receptacle
Number of Rows = Dual
得捷:
CONN RCPT HSG 18POS 2.54MM
艾睿:
TE Connectivity&s;s 1-87456-3 discrete wire housing can make a durable connection between discrete wires. This RCP connector has 18 RCP contacts. It has a receptacle type gender. It has a maximum voltage rating of 250 VAC. It has a straight body orientation. This is a 2-row connector. Its pitch is 2.54 mm. This device has a maximum current rating of 3 A/contact. 1-87456-3 is housed in black nylon. This rectangle connector has an operating temperature of -65 to 105 °C. This product is 25.4 mm long, 6.1 mm tall and 15.24 mm deep.
安富利:
Conn Housing RCP 18 POS 2.54mm Crimp ST Cable Mount
Verical:
Conn Housing RCP 18 POS 2.54mm Crimp ST Cable Mount Black Package
Newark:
# AMP - TE CONNECTIVITY 1-87456-3 18 MODIV HSG COMP DR .100CL New
MASTER:
HOUSING, MOD IV DOUBLE ROW, .100X.100 C/L CRIMP SNAP-IN, SHORT ENTRY
Powell:
.100 AMPMODU Headers, Housings & Contacts
Online Components:
18 MODIV HSG COMP DR .100CL
Electro Sonic:
18 MODIV HSG COMP DR .100CL
触点数 18
极性 Female
额定电压AC 250 V
绝缘电阻 5000 MΩ
排数 2
易燃性等级 UL 94 V-0
针脚数 18
触点额定电流 3.00 A
额定电流Max 3A/触头
工作温度Max 105 ℃
工作温度Min -65 ℃
额定电压Max 250 VAC
引脚间距 2.54 mm
高度 15.24 mm
引脚间距 2.54 mm
外壳颜色 Black
颜色 Black
触点材质 Beryllium Copper
工作温度 -65℃ ~ 105℃
外壳材质 Nylon
产品生命周期 Active
包装方式 Bulk
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ELV标准 Compliant
ECCN代码 EAR99
HTS代码 8538906000
