1-102448-0

集管和线壳 HSG DUAL 24P 22-20

24 Position Rectangular Receptacle Connector IDC Gold 20-22 AWG

得捷:
CONN RCPT 24P IDC 20-22AWG GOLD

贸泽:
集管和线壳 HSG DUAL 24P 22-20

艾睿:
Reduce the possibility of accidentally shorting pins when using a printed circuit board with this idc connector 1-102448-0 header connector from TE Connectivity. This RCP connector&s;s 24 contacts that are made out of copper alloy and plated with gold over nickel. It has a receptacle type gender. This is a 2-row connector. It has a straight body orientation. Its pitch is 2.54 mm. This device has a maximum current rating of 3 A/contact. The component will be shipped in tray format. This product is 30.48 mm long, 6.1 mm tall and 15.24 mm deep. This connector has an operating temperature of -65 to 105 °C. It uses the idt termination method. 1-102448-0 is housed in black polybutylene terephthalate.

Verical:
CONN 24 AMPMODU MT ASSY DR .100CL

Powell:
.100 AMPMODU Headers, Housings & Contacts

Electro Sonic:
24 AMPMODU MT ASSY DR .100CL
