1-641215-8

Conn Wire to Board HDR 18POS 2.54mm Solder ST Thru-Hole

针座 通孔 18 位置 0.100"（2.54mm）

得捷:
CONN HEADER VERT 18POS 2.54MM

艾睿:
As an added safety precaution, the wire to board 1-641215-8 header connector from TE Connectivity will prevent and protect components on your circuit board from accidentally touching each other. This HDR connector&s;s 18 contacts that are made out of copper alloy and plated with gold over nickel. It has a straight body orientation. Its pitch is 2.54 mm. This is a 1-row connector. It has a header type gender. It has a maximum voltage rating of 250 VAC. This device has a maximum current rating of 5 A/contact. This product is 45.72 mm long, 10.03 mm tall and 5.71 mm deep. This connector has an operating temperature of -55 to 105 °C. It uses the solder termination method. 1-641215-8 is housed in white polyester.

Chip1Stop:
Conn Wire to Board HDR 18 POS 2.54mm Solder ST Thru-Hole

Verical:
Conn Wire to Board HDR 18 POS 2.54mm Solder ST Thru-Hole Package

MASTER:
Conn Wire to Board HDR 18 POS 2.54mm Solder ST Thru-Hole Package

Online Components:
18P MTA100 HDR ASSY FL/ST 30AU

Electro Sonic:
18P MTA100 HDR ASSY FL/ST 30AU
