1-178298-2

Dynamic D-3100 系列管座TE Connectivity Dynamic 系列的 D-3100 系列管座具有镀锡固定支脚，以提高稳定性。 D-3100 系列管座的印刷电路板焊接尾线为镀锡，触点插片为镀金。 这些 D-3100 系列管座的建议印刷电路板厚度为 1.0 至 1.6mm。### 注有关配接的 D-3100 系列外壳，请参见典型库存号 680-1571### TE Connectivity Dynamic 3000 系列### Tyco 动态 3000 系列

Dynamic D-3100 系列管座

Dynamic 系列的 D-3100 系列管座具有镀锡固定支脚，以提高稳定性。 D-3100 系列管座的印刷电路板焊接尾线为镀锡，触点插片为镀金。 这些 D-3100 系列管座的建议印刷电路板厚度为 1.0 至 1.6mm。

### 注

有关配接的 D-3100 系列外壳，请参见典型库存号 680-1571

得捷:
CONN HEADER R/A 10POS 3.81MM

立创商城:
1-178298-2

欧时:
### Dynamic D-3100 系列管座TE Connectivity Dynamic 系列的 D-3100 系列管座具有镀锡固定支脚，以提高稳定性。 D-3100 系列管座的印刷电路板焊接尾线为镀锡，触点插片为镀金。 这些 D-3100 系列管座的建议印刷电路板厚度为 1.0 至 1.6mm。### 注有关配接的 D-3100 系列外壳，请参见典型库存号 680-1571### TE Connectivity Dynamic 3000 系列### Tyco 动态 3000 系列

贸泽:
集管和线壳 .150 10P HDR HOR

e络盟:
线至板连接器, Dynamic D-3100S系列, 10 触点, 针座, 3.81 mm, 通孔安装, 1 排

艾睿:
There won&s;t be any energy loss when you power up your circuit using the 1-178298-2 power connector from TE Connectivity. This M connector&s;s 10 contacts that are made out of copper alloy and plated with gold over nickel. It has a male type gender. This connector has a single port. Its pitch is 3.81 mm. It has a maximum voltage rating of 250 VAC. It has a right angle body orientation. 1-178298-2 is housed in polyester. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. Its 10 terminals use the solder termination method. This power connector has a minimum operating temperature of -55 °C and a maximum of 105 °C. This product is 48.29 mm long, 10.85 mm tall and 22.1 mm deep.

Allied Electronics:
Dynamic 3000 Series, 3.81mm Pitch 10 WayRight Angle PCB Header, Solder Term

安富利:
Conn Power M 10 POS 3.81mm Solder RA Thru-Hole 10 Terminal 1 Port Tube

Chip1Stop:
Conn Power M 10 POS 3.81mm Solder RA Thru-Hole 10 Terminal 1 Port Tube

Verical:
Conn Power M 10 POS 3.81mm Solder RA Thru-Hole 10 Terminal 1 Port Tube

Newark:
# AMP - TE CONNECTIVITY  1-178298-2  Wire-To-Board Connector, Dynamic D-3100S Series, Through Hole, Header, 10, 3.81 mm

MASTER:
DYNAMIC HDR ASSY H 10P

Powell:
Dynamic Series Connectors

Online Components:
DYNAMIC HDR ASSY H 10P

Electro Sonic:
DYNAMIC HDR ASSY H 10P
