104352-5

集管和线壳 10 MODII HDR DRST B/

10 MODII HDR DRST B/A W/HD

得捷:
CONN HEADER VERT 10POS 2.54MM

贸泽:
集管和线壳 10 MODII HDR DRST B/

艾睿:
This unshrouded 104352-5 header connector from TE Connectivity is used for jumper posts to support physical configuration options on printed circuit boards. This HDR connector&s;s 10 contacts that are made out of phosphor bronze and plated with tin-lead over nickel. This is a 2-row connector. It has a header type gender. Its pitch is 2.54 mm. It has a straight body orientation. This device has a maximum current rating of 3 A/contact. 104352-5 is housed in black thermoplastic. This product is 12.29 mm long, 8.12 mm tall and 4.87 mm deep. It uses the solder termination method. This connector has an operating temperature of -65 to 105 °C.

安富利:
Conn Unshrouded Header HDR 10 POS 2.54mm Solder ST Thru-Hole

Verical:
Conn Unshrouded Header HDR 10 POS 2.54mm Solder ST Thru-Hole Carton

Powell:
.100 inch AMPMODU Headers

Online Components:
10 MODII HDR DRST B/A W/HD

Electro Sonic:
10 MODII HDR DRST B/A W/HD
