1-86479-0

Conn Unshrouded Header HDR 26POS 2.54mm Solder RA Thru-Hole

26 MODII HDR DRRA UNSHRD .100

Product Highlights

Connector

With Contacts

Housing Gender = Header - Pin

Contact Gender = Pin

Header Type = Standard

得捷:
CONN HEADER R/A 26POS 2.54MM

贸泽:
Headers & Wire Housings UNSHRD R.A. DUAL 26P

艾睿:
Use this unshrouded 1-86479-0 connector from TE Connectivity when board-to-board interconnects is required. This HDR connector&s;s 26 contacts that are made out of copper alloy and plated with gold over nickel. This is a 2-row connector. Its pitch is 2.54 mm. It has a right angle body orientation. It has a header type gender. This device has a maximum current rating of 3 A/contact. This component will be shipped in tray format. This connector has an operating temperature of -65 to 105 °C. This product is 32.61 mm long, 6.04 mm tall and 15.42 mm deep. 1-86479-0 is housed in black thermoplastic. It uses the solder termination method.

安富利:
Conn Unshrouded Header HDR 26 POS 2.54mm Solder RA Thru-Hole

Chip1Stop:
Conn Unshrouded Header HDR 26 POS 2.54mm Solder RA Thru-Hole Tray

Verical:
Conn Unshrouded Header M 26 POS 2.54mm Solder RA Side Entry Thru-Hole Tray

MASTER:
ASSEMBLY, MOD II, DOUBLE ROW .100 X .100 CL, RIGHT ANGLE WITH SPANKED TAILS

Powell:
.100 inch AMPMODU Headers

Online Components:
26 MODII HDR DRRA UNSHRD .100

Electro Sonic:
26 MODII HDR DRRA UNSHRD .100
