1-1827873-5

TE CONNECTIVITY  1-1827873-5  线至板连接器, Dynamic D-1100D系列, 10 触点, 针座, 2 mm, 通孔安装, 2 排

Dynamic 1100 系列管座

动态系列的 D-1100 系列管座具有镀锡固定支脚，以提高稳定性。 D-1100 系列管座的印刷电路板焊接尾线为镀锡，触点插片为镀金。 这些 D-1100 系列管座的建议印刷电路板厚度为 1.0 至 1.6mm。 D-1100 系列管座的设计有助于在配接期间防止触点弯曲。

### 注

有关匹配的 D-1100 系列外壳，请参见典型库存号 706-4411。

### TE Connectivity Dynamic 1000 系列

得捷:
CONN HEADER R/A 10POS 2MM

欧时:
TE Connectivity PCB 针座 Dynamic 1000 系列 10路 2mm节距 直角 1-1827873-5, 焊接端接, 3A, 通孔

立创商城:
2mm 2x5P 弯插

e络盟:
线至板连接器, 2 mm, 10 触点, 针座, Dynamic D-1100D Series, 通孔安装, 2 排

艾睿:
There won&s;t be any energy loss when you power up your circuit using the 1-1827873-5 power connector from TE Connectivity. This HDR connector&s;s 10 contacts that are made out of copper alloy and plated with gold over nickel. It has a right angle body orientation. It has a header type gender. This connector has a single port. Its pitch is 2 mm. It has a maximum voltage rating of 250 VAC. 1-1827873-5 is housed in polyester. This device has a maximum current rating of 3 A/contact. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This product is 12.6 mm long, 11.8 mm tall and 15 mm deep. Its 10 terminals use the solder termination method. This power connector has a minimum operating temperature of -55 °C and a maximum of 105 °C.

Allied Electronics:
Conn; Rect; Plug/Header; Horiz; 2mm Pitch; 10 Pos; 2-Row; X-Key; Dynamic Ser/D-1100D

Chip1Stop:
Conn Power HDR 10 POS 2mm Solder RA Thru-Hole 10 Terminal 1 Port Automotive Tube

Verical:
Conn HDR and Receptacle 10 POS 2mm Solder RA Thru-Hole 10 Terminal 1 Port Tube

Newark:
# TE CONNECTIVITY  1-1827873-5  Wire-To-Board Connector, Dynamic D-1100D Series, Through Hole, Header, 10, 2 mm

Powell:
Dynamic Series Connectors
