1.14.100.501/0000

RAFI  1.14.100.501/0000  按钮开关, SPST-常开, 35 V, 100 mA, 焊接

The is a single-pole single-throw Short-travel Key switch with THT outward terminals, 1NO contact type, gold contact and snap-action contact. The short-travel key switch offers an extremely high switching reliability while needing very little space. It can be arranged as single key, in rows or key blocks. When arranged under an overlay, RACON key switch should be combined with plungers. Suitable for wave soldering bath.

.

100mR Maximum contact resistance

.

10⁹R Insulation resistance

.

-40 to +90°C Operating temperature range
