TE CONNECTIVITY 1888174-4 输入输出连接器, Everclear Mini-SAS系列, SATA, 插座, 36 触点, 通孔安装, 电路板安装
36 位置 SAS,迷你型 插座 焊接 表面贴装型
得捷:
CONN MINI SAS RCPT 36POS SLD SMD
立创商城:
1888174-4
贸泽:
I/O Connectors Vert Combo 36 POS 2.8mm Dual Key
e络盟:
输入输出连接器, Everclear Mini-SAS系列, SATA, 插座, 36 触点, 通孔安装, 电路板安装
艾睿:
Devices such as printers and scanners that run the Small Computer System Interface standards and protocols will require this sata 1888174-4 SCSI connector from 1888174-4 in order to interface with each other. This RCP connector&s;s 36 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a straight body orientation. It has a receptacle type gender. This connector has a single port. Its pitch is 0.8 mm. 1888174-4 is housed in liquid crystal polymer. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This product is 12.07 mm deep. Its 36 terminals use the solder termination method.
Allied Electronics:
Receptacle, EVERCLEAR, Mini-SAS, Internal, Vertical Combo, 36 Pos, Dual Key
安富利:
Conn SATA RCP 36 POS 0.8mm Solder ST SMD 36 Terminal 1 Port Tube
Chip1Stop:
Conn SATA RCP 36 POS 0.8mm Solder ST SMD 36 Terminal 1 Port Tube
Verical:
Conn SATA RCP 36 POS 0.8mm Solder ST SMD 36 Terminal 1 Port Tube
Newark:
# TE CONNECTIVITY 1888174-4 I/O Connector, 36 Contacts, Receptacle, SATA, Surface Mount, Everclear Mini-SAS Series, PCB Mount
MASTER:
EVERCLEAR Mini-SAS VERTICAL INTERNAL RECEPTACLE ASSY WITH DUAL KEYED SHELL
Powell:
Serial ATA & Serial Attached SCSI
Online Components:
Mini-SAS Rcpt Assy V w/ Shld T
Electro Sonic:
Mini-SAS Rcpt Assy V w/ Shld T
触点数 36
极性 Female
触点电镀 Gold
方向 Vertical
针脚数 36
额定电流Max 0.5A/触头
工作温度Max 105 ℃
工作温度Min -55 ℃
安装方式 Surface Mount
封装 -
高度 21.08 mm
封装 -
触点材质 Phosphor Bronze
产品生命周期 Active
包装方式 Tube
制造应用 Signal
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ELV标准 Compliant
REACH SVHC标准 No SVHC
ECCN代码 EAR99
HTS代码 8536694040
