1977477-2

TE CONNECTIVITY  1977477-2  接线端子块, 有隔板

电路 0.325"（8.26mm） 隔板接线座 螺钉，带紧固板

得捷:
CONN BARRIER STRIP 2CIRC 0.325"

立创商城:
8.26mm 每排P数:2 排数:1

e络盟:
接线端子块, 有隔板

艾睿:
This barrier strip 1977477-2 PCB terminal block manufactured from TE Connectivity will bridge different sections of wires together. Its pitch is 8.25 mm. It has a straight body orientation. This is a 1-row connector. It has a maximum voltage rating of 300 VAC. This device has a maximum current rating of 15 A/contact. 1977477-2 is housed in polyamide. It uses the solder termination method. This product is 13.7 mm deep. This quick disconnect terminal has an operating temperature of -40 to 105 °C. Its wire is 16-22 AWG.

安富利:
Conn Barrier Strip 2 POS 8.25mm Solder ST Thru-Hole 15A/Contact Box

Chip1Stop:
Conn Barrier Strip 2 POS 8.25mm Solder ST Thru-Hole 15A/Contact Box

Verical:
Conn Barrier Strip 2 POS 8.25mm Solder ST Thru-Hole 15A/Contact Carton

Newark:
# TE CONNECTIVITY  1977477-2  PCB Mount Barrier Terminal Block, 8.25 mm, 1 Row, 2 Positions, 22 AWG, 16 AWG, 15 A

MASTER:
DUAL BARRIER, TERMINAL BLOCK 8.25mm PITCH

Powell:
Barrier Style Terminal Blocks

Online Components:
DUAL BARRIER, TERMINAL BLOCK 8.25mm PITCH

Electro Sonic:
Module Dual Barrier, .325 CL, 2 Pos.
