AMP FROM TE CONNECTIVITY 1-84984-9 连接器, FFC, 母 19路 1MM
1mm FFC DIP V ASSY 19P NATTB
Product Highlights
1.00 mm Centerline
Number of Positions = 19
PCB Mount Angle = Vertical
PCB Mount Style = Thru Hole
Contact Type = Top
得捷:
CONN FFC FPC VERT 19POS 1MM PCB
e络盟:
连接器, FFC, 母 19路 1MM
艾睿:
Look no further than fpc connector 1-84984-9 flexible flat cable from TE Connectivity, the perfect solution for embedding a greater number of electrical lines within a tightly constrained space. This is a 1-row connector. This socket type connector&s;s 19 contacts that are made out of phosphor bronze and plated with tin over nickel. It has a straight body orientation. Its pitch is 1 mm. It has a maximum voltage rating of 125 VAC. This device has a maximum current rating of 1 A/contact. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. It uses the solder termination method. This product is 21 mm long, 5.6 mm tall and 3 mm deep. 1-84984-9 is housed in natural polybutylene terephthalate. This flexible flat cable has an operating temperature of -20 to 85 °C.
安富利:
Conn FPC Connector SKT 19 POS 2mm Solder ST Thru-Hole Tube
Chip1Stop:
Conn FPC Connector SKT 19 POS 1mm Solder ST Thru-Hole Tube
Verical:
Conn FPC Connector SKT 19 POS 1mm Solder ST Thru-Hole Tube
Newark:
FFC / FPC Board Connector, 1 mm, 19 Contacts, Receptacle, FPC Series, Through Hole, Top
MASTER:
ASSY, 1.00mm FFC CONN DIP, V
Powell:
FPC Flexible Printed Circuit Connectors
Online Components:
ASSY, 1.00mm FFC CONN DIP, V
AMEYA360:
CONN FFC FPC VERT 19POS 1MM PCB
Electro Sonic:
1mm FFC DIP V ASSY 19P NATTB
触点数 19
极性 Female
触点电镀 Tin
额定电流 1 A
排数 1
方向 Vertical
易燃性等级 UL 94 V-0
针脚数 19
屏蔽 No
额定电流Max 1A/触头
工作温度Max 85 ℃
工作温度Min -20 ℃
额定电压Max 125 VAC
额定电压 125 V
安装方式 Through Hole
长度 21 mm
宽度 3 mm
高度 5.6 mm
外壳颜色 White
触点材质 Phosphor Bronze
工作温度 -20℃ ~ 85℃
产品生命周期 Active
包装方式 Tube
制造应用 Signal
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ELV标准 Compliant
ECCN代码 EAR99
HTS代码 8536694040
