Phoenix Contact PCB 接线端子块 COMBICON MC 系列 4路 5.08mm节距 1847482, 焊接端接, 8A
Conn Wire to Board HDR 4 POS 5.08mm Solder RA Thru-Hole
得捷:
TERM BLOCK HDR 4POS 90DEG 5.08MM
欧时:
Base Strip 1847482
立创商城:
5.08mm 排数:1 每排P数:4
艾睿:
Mounting this wire to board 1847482 header connector from Phoenix Contact to your printed circuit board can help you support multiple physical configuration options. This HDR connector has 4 contacts that are plated with tin. It has a right angle body orientation. This is a 1-row connector. It has a header type gender. It has a maximum voltage rating of 320 V. Its pitch is 5.08 mm. This device has a maximum current rating of 8 A. This product is 29.44 mm long, 7.25 mm tall and 9.2 mm deep. It uses the solder termination method. 1847482 is housed in green polybutylene terephthalate.
Verical:
Conn Wire to Board HDR 4 POS 5.08mm Solder RA Thru-Hole
MASTER:
PCB headers - nominal current: 8 A - rated voltage III/2: 320 V - nominal cross section: 1.5 mm² - number of positions: 4 - pitch: 5.08 mm - color: green - contact surface: Tin - mounting: Wave soldering - pin layout: Linear pinning - solder pin [P]: 3.
Online Components:
Conn Wire to Board HDR 4 POS 5.08mm Solder RA Thru-Hole
Electro Sonic:
PCB headers - nominal current: 8 A - rated voltage III/2: 320 V - nominal cross section: 1.5 mm² - ...
