可插拔接线端子 2P UNSHROUD 5.0 HDR
2 针位端子块 接头，公引脚，无罩 0.197"（5.00mm） 垂直 - 通孔
得捷:
TERM BLOCK HDR 2POS VERT 5MM
贸泽:
可插拔接线端子 2P UNSHROUD 5.0 HDR
艾睿:
As an added safety precaution, the unshrouded 1546931-2 header connector from TE Connectivity will prevent and protect components on your circuit board from accidentally touching each other. This HDR connector&s;s 2 contacts that are made out of brass and plated with tin. This is a 1-row connector. It has a straight body orientation. Its pitch is 5 mm. It has a maximum voltage rating of 300 VAC. It has a header type gender. This device has a maximum current rating of 12 A/contact. This product is 10 mm long, 9 mm tall and 2.8 mm deep. It uses the solder termination method. 1546931-2 is housed in black polyamide 6/6.
安富利:
Conn Unshrouded Header HDR 2 POS 5mm Solder ST Thru-Hole
Verical:
Conn Unshrouded Header M 2 POS 5mm Solder ST Top Entry Thru-Hole
Newark:
# AMP - TE CONNECTIVITY 1546931-2 2P UNSHROUD 5.0 HDR,HIGH TEMP New
MASTER:
TERMINAL BLOCK, PIN HEADER, UNSHROUDED, HIGH TEMPERATURE, 5.0mm PITCH
Powell:
Terminal Block Connectors
Online Components:
2P UNSHROUD 5.0 HDR,HIGH TEMP
Electro Sonic:
2P UNSHROUD 5.0 HDR,HIGH TEMP
