TE Connectivity 系列### TE Connectivity Between-Series RF Coaxial Adapters
系列
得捷:
CONN ADAPT PLUG-JACK OSM 50 OHM
欧时:
TE Connectivity 50Ω 直角 射频适配器 1055070-1, 0 → 18GHz, SMA 插头 到 SMA 插座, 铍铜触芯
e络盟:
射频/同轴适配器, SMA, 插头, SMA, 插座, 直角转接器, 50 ohm
艾睿:
Conn SMA Adapter PL/RCP 0Hz to 18GHz 50Ohm RA Gold Over Copper Package
Allied Electronics:
Adapter; Plug-Jack; Stainless Steel; Beryllium Copper; TFE Fluorocarbon
安富利:
Conn SMA Adapter PL/RCP 0Hz to 18GHz 50Ohm RA Gold Over Copper
Chip1Stop:
Conn SMA Adapter PL/RCP 0Hz to 18GHz 50Ohm RA Gold Over Copper
Verical:
Conn SMA Adapter PL/RCP 0Hz to 18GHz 50Ohm RA Gold Over Copper Package
Newark:
# AMP - TE CONNECTIVITY 1055070-1 RF / Coaxial Adaptor, 50 OHM, 18GHZ, Intra Series Coaxial, Right Angle Adapter, SMA, Plug, SMA
MASTER:
RF / Coaxial Adapter - SMA - Plug - SMA - Jack - Right Angle Adapter - 50 ohm.
Online Components:
2088 1230 02
ICbanQ:
RF Connectors SMA ADAPTER
Electro Sonic:
RF / Coaxial Adapter - SMA - Plug - SMA - Jack - Right Angle Adapter - 50 ohm.
触点电镀 Gold
拔插次数 500
工作温度Max 125 ℃
工作温度Min -65 ℃
额定电压 335 V
安装方式 Through Hole
封装 SMA
长度 17.1 mm
宽度 7.9 mm
高度 17.1 mm
封装 SMA
触点材质 Beryllium Copper
介质材料 Tetrafluoroethylene TFE
工作温度 -65℃ ~ 125℃
产品生命周期 Active
制造应用 通信与网络, Power, 射频通信, Signal, RF Communications, Communications & Networking
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ELV标准 Compliant
REACH SVHC标准 No SVHC
ECCN代码 EAR99
HTS代码 8536694010
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
1055070-1 TE Connectivity 泰科 | 当前型号 | 当前型号 |
2088 1230 02 泰科 | 完全替代 | 1055070-1和2088 1230 02的区别 |
132172 Connex | 类似代替 | 1055070-1和132172的区别 |
