WEIDMULLER 1716550000 插拔式接线端子, 10 路, 300 V, 10 A, 5.08 mm, 22 AWG, 12 AWG
The is a 10-pole black female PCB Plug-in Connector with pressure clamp connection. The BL 5.08/10/180 SN BK BX connector has tinned CuSn contact with 4 to 8µm Sn hot-dip tinned layer structure of plug contact and a PA insulator. The female plug has leaf-spring wire connection system. The female plug provides space for labelling.
- .
- >=10⁸R Insulation resistance
- .
- 4.6mR Volume resistance
- .
- DIN 5264 Screwdriver blade standard
- .
- UL94V-2 Flammability
- .
- -50 to 100°C Operating temperature range
触点数 10
线规 14AWG ~ 26AWG
触点电镀 Tin
额定电流 10 A
排数 1
电路数 10
易燃性等级 UL 94 V-2
针脚数 10
安装角度 180 °
额定电流Max 15 A
额定电压Max 300 V
额定电压 300 V
工作电压Max 300 V
安装方式 Screw
引脚间距 5.08 mm
长度 50.8 mm
宽度 17.4 mm
高度 12.5 mm
引脚间距 5.08 mm
外壳颜色 Orange
颜色 Black
触点材质 Copper Alloy
工作温度 -25℃ ~ 100℃
外壳材质 Nylon
产品生命周期 Last Time Buy
包装方式 Box
制造应用 Industrial, 工业
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/12/17
ECCN代码 EAR99
HTS代码 8536694050
