1766436-1

TE CONNECTIVITY  1766436-1  卡边连接器, 母, 30路

283-0172-04003=TA CONN,SKT

Product Highlights

Intel VRM 10.2 Specification, Intel VRM 11.0 Specification

PCB Thickness = 1.57 mm

Tail Length = 3.8 mm

12 Power Contacts

Number of Signal Contacts = 18

得捷:
CONN EDGE DUAL FMALE 30POS GOLD

立创商城:
P数:30

e络盟:
卡边连接器, 母, 30路

艾睿:
When space for electrical connections on printed circuit boards is limited then it is in your favor to use this 1766436-1 smart card connector from TE Connectivity. This SKT connector&s;s 12power / 18signal contacts that are made out of copper alloy and plated with gold over nickel. It has a socket type gender. It has a straight body orientation. It has a maximum voltage rating of 250 VAC. This is a 2-row connector. This product is 9 mm tall. This device has a maximum current rating of 25 A. It uses the press fit termination method. 1766436-1 is housed in thermoplastic. This card edge connector has an operating temperature of -55 to 105 °C.

Verical:
Conn Card Edge SKT 12Power/18Signal POS Press Fit ST Thru-Hole Box

Newark:
# TE CONNECTIVITY  1766436-1  Connector, Mini CROWN EDGE Series, Card Edge, 30 Contacts, Receptacle, 2.5 mm, Through Hole

Powell:
Mini CROWN EDGE High Current Connectors

Online Components:
283-0172-04003=TA CONN,SKT

Electro Sonic:
Conn Card Edge SKT 12Power/18Signal POS Press Fit ST Thru-Hole Box
